Software Module 1
USD110
Software module 1 – Fiat, Lancia, Citroen, Peugeot immobox Delphi
Memory device is serial memory 93c46 SMD8 package.
Expected file size is 128 bytes.
Use TMPro chip or T5 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
✅ Fiat: Barchetta, Brava, Bravo(-1998), Cinquecento, Ducato(-2001), Marengo, Panda(-2002), Punto(-1999), Seicento(-1999), Tempra
✅ Lancia: Dedra, Delta
✅ Citroen: Jumper(-2001), Relay(-2001)
✅ Peugeot: Boxer(-2001)
