Memory device is Motorola 9S12XEQ384 112-pin QFP package.
You can read Motorola with TMPro, view connection diagram.
Expected file size is 4096 bytes.
Use TMPro chip or K-JMD transponder.
Software shows PIN code.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
✅ Chevrolet:Sail (2016-), Aveo (2016-)
