Memory device is Motorola MC9S12XEP768.
You can read Motorola with TMPro, view connection diagram.
Expected file size is 4096 bytes.
Use TMPro chip or K-JMD transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
✅ Ford: F-150
