Memory device is Renesas R5F10BAGL 30 pin SMD package.
You can read and write Renesas with TMPro, view connection diagram.
Expected file size is 4096 bytes.
Use TMPro chip or PCF7938XA transponder, for example THIS .
Written transponder is ready programmed to start the bike.
Vehicles equipped with this unit:
✅ KTM: 790, 890, 990, 1090, 1190, 1290
