Memory device is serial eeprom 24c04 or 24c16 both SMD8 package.
Software shows PIN code.
Expected file size for 24c04 is 512 bytes, for 24c16 is 2048 bytes.
Use PCF7935 or Silca T15 – JMA TP14 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
✅ Volkswagen: Lupo(2000-2002), Polo(2000-2002), Transporter(2000-2002)
✅ Seat: Arosa(2000-2002), Alhambra(2000-2002), Inca(2000-2002)
✅ Ford: Galaxy(2000-2002)
