Software Module 37
USD110
Software module 37 – Mercedes Actros, Atego engine ECU Temic
Memory device is serial eeprom, which can be 93c56, 93c66, 93c86,25c640 or 95c128, all SMD8 package.
For 93c56 expected file size is 256 bytes, for 93c66 expected file size is 512 bytes, for 93c86 is 2048 bytes,for 25c640 is 8192 bytes and for 95c128 is 16384 bytes.
Use TMPro chip or T5 transponder.
Written transponder is ready programmed to start the truck.
Vehicles equipped with this unit:
✅ Mercedes trucks: Actros(1998-), Atego(1998-), Axor(1998-), Econic(1998-)
