Memory device is PIC16F690 SSOP20 package.
You can read PIC16F690 with TMPro, view connection diagram
Use TMPro chip or K-JMD transponder.
Written transponder is ready programmed to start the bike.
Vehicles equipped with this unit:
✅ MV Agusta:Brutale, Stradale
